NICOR 17014A-LED-ID 6" Airtight Shallow Housing
NICOR 17014A-LED-ID Airtight New Construction Housing



Alternative Views:
Our Price: $18.99



Product Code: 17014A-LED-ID
Qty:

Description Technical Specs


NICOR 17014A-LED-ID 6" Airtight New Construction Housing


The NICOR 17014A-LED-ID is the most popular housing for LED downlights in new construction applications for both residential and commercial use. The IDEAL connection that is included with the can allows for simple, snap-in connection with NICOR D-Series LED recessed and surface mount downlights. The 17014A includes a one-year warranty and is IC-rated, damp location listed, and certified for direct contact with insulation.


NICOR 17014A-LED-ID Housing cULus Listed NICOR 17014A-LED-ID Housing Damp Location Listed
Features

17014A-LED-ID Housing Specs and Features:
  • The 17014A is constructed with aluminum, which provides greater heat dissipation
  • The Airtight ratings means that the exchange of air between the ceiling plenum and heated/cooled areas is limited
  • This housing is Washington State Energy Code approved to meet restricted airflow requirements
  • The integral thermal protector protects against misuse of insulation and improper lamping
  • The 17014A-LED-ID assures consistent and proper lamp positioning because of the adjustable socket bracket
  • The housing can be used in 2" x 6" joist construction because of the 5 1/2" height

17014A-LED-ID Plaster Frame:
  • The housing is screwed to the plastic frame and can be removed to access the j-box
  • The 17014A can be adjusted from 1/2" to 1 1/2" for ceiling thickness

17014A-LED-ID Junction Box Information:
  • The 17014A is listed for through branch circuit wiring and includes several 3/4” knockouts
  • Four pryouts with integral strain relief make Romex installation easy
  • The housing includes three push-in wire connectors

17014A-LED-ID Hanger Bars:
  • The hangar bars are heavy-gauge to provide stability, which means the housing can be positioned at any point within a 24" join span then screwed in place
  • The can is easily aligned to the joist with the unique hangar bar lip design
  • Installation is simple with four double-headed captive nails
  • The bars can be repositioned 90° on plaster frame without tools
  • The bars fit onto T-bar spine for quick alignment and can be permanently secured
  • The bars can be shortened without tools to accommodate a 12" joist span because of the score lines
